    635nm 1W 2W High Power 9mm TO5 Red Laser Diode Multi Mode FAC Optional Orange Red Laser Diode

    Ask Lasest Price
    Brand Name : XINLAND
    Model Number : XLD-635 Laser Diode
    Certification : CE
    Price : Negotiated
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 1000 Dozen/Dozens per Day
    Delivery Time : 7 days
    • Product Details
    • Company Profile

    635nm 1W 2W High Power 9mm TO5 Red Laser Diode Multi Mode FAC Optional Orange Red Laser Diode

    635nm 1W 2W High Power 9mm TO5 Red Laser Diode Multi Mode FAC Optional Orange Red Laser Diode


    Product Details​:

    Model Number: XLD-635 (FAC Optional)

    Type: Laser Diode

    Laser Type: Orange Red Laser

    Power: 1W/2W

    Wavelength: 635nm

    Package Type: TO5

    Product Specifications:

    WavelengthPart NumberOutput PowerMode TypeLaser TypePackagePDFAC
    635nmXLD-635-500m-C500mWMMFPC-mount×
    XLD-635-500m-1-FAC500mWMMFPTO18×
    XLD-635-700m-1700mWMMFPTO18××
    XLD-635-001-21WMMFPTO5×
    XLD-635-002-22WMMFPTO5×
    XLD-635-001-2-FAC1WMMFPTO5×
    XLD-635-002-2-FAC2WMMFPTO5×

    635nm 1W 2W High Power 9mm TO5 Red Laser Diode Multi Mode FAC Optional Orange Red Laser Diode

    Precautions:

    1. This component is sensitive to static electricity. Do not touch the laser tube body directly with your hands without taking anti-static measures.
    2. This product must have a qualified drive circuit to work normally, the voltage of different power is the same, but the working current is different.
    3. The driving current of the circuit to the tube needs to be controlled within a safe range, otherwise it will affect the life.

    4. The laser tube should be stored or worked in a dry environment to prevent condensation, which will damage the laser tube.
